iEVLEAD Type2 Model3 11KW Charging point Home EV Charger


  • Model: AB2-EU11-RS
  • Max.Output Power: 11KW
  • Working Voltage: AC400V/Three Phase
  • Working Current: 16A
  • Charging Display: LCD Screen
  • Output Plug: IEC 62196,Type 2
  • Function: Plug & Charge/RFID
  • Cable Length: 5M
  • Connectivity: OCPP 1.6 JSON (OCPP 2.0 compatible)
  • Sample: Support
  • Customization: Support
  • OEM/ODM: Support
  • Certificate: CE,ROHS
  • IP Grade: IP65
  • Warranty: 2 years
  • Product Detail

    Product Tags

    Production Introduction

    The iEVLEAD EV Charger is equipped with a Type2 connector (EU Standard, IEC 62196), which is compatible with all electric vehicles on the road. It features a visual screen and supports RFID charging for electric cars. The EV Charger has obtained CE and ROHS certifications, ensuring compliance with high safety standards set by the leading organization. It is available in both wall-mounted and pedestal-mounted configurations, and comes with a standard 5-meter cable length option.

    Features

    1. Designs with compatibility for 11KW charging power.
    2. Compact size and sleek design.
    3. Intelligent LCD screen.
    4. RFID-controlled charging station for home use.
    5. Intelligent charging and load distribution.
    6. High level of protection (IP65) against challenging environments.

    Specifications

    Model AB2-EU11-RS
    Input/Output Voltage AC400V/Three Phase
    Input/Output Current 16A
    Max Output Power 11KW
    Frequency 50/60Hz
    Charging Plug Type 2 (IEC 62196-2)
    Output Cable 5M
    Withstand Voltage 3000V
    Work Altitude <2000M
    Protection over voltage protection, over load protection, over-temp protection, under voltage protection, earth leakage protection, lightning protection, short circuit protection
    IP level IP65
    LCD Screen Yes
    Function RFID
    Network No
    Certification CE, ROHS

    Application

    ap01
    ap02
    ap03

    FAQs

    1. What are your shipping conditions?
    A: By express, air and sea. The customer can choose anyone accordingly.

    2. How to order your products?
    A: When you are ready to order, please contact us to confirm the current price, payment arrangement and delivery time.

    3. What is your sample policy?
    A: We can supply the sample if We have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

    4. Can AC charging piles be used for other electronic devices?
    A: AC charging piles are specifically designed for electric vehicles and may not be compatible with other electronic devices. However, some charging piles may have additional USB ports or outlets to charge other devices simultaneously.

    5. Are AC charging piles safe to use?
    A: Yes, AC charging piles are generally safe to use. They undergo rigorous testing and meet international safety standards to ensure the safety of users and their vehicles. It is recommended to use certified, reliable charging piles and follow the manufacturer's instructions for safe usage.

    6. Are AC charging piles weather-resistant?
    A: AC charging piles are usually designed to be weather-resistant. They are constructed using durable materials and have protective measures to withstand various weather conditions, including rain, snow, and high temperatures. However, it is recommended to check the specifications of the charging pile for its specific weather resistance capabilities.

    7. Can I use a charging pile from a different brand with my electric vehicle?
    A: In most cases, electric vehicles are compatible with different brands of charging piles as long as they use the same charging standard and connector type. However, it is always advisable to consult the vehicle manufacturer or the charging pile manufacturer to ensure compatibility before use.

    8. How can I find an AC charging pile near me?
    A: To find an AC charging pile near your location, you can use various online platforms, mobile applications, or websites dedicated to EV charging station locators. These platforms provide real-time information on available charging stations, including their locations and availability.
