iEVLEAD Smart Wifi 11.5KW Level2 EV Charging Station

Model: AB2-US11.5-WS

Max.Output Power: 11.5KW

Working Voltage: AC110-240V/Single Phase

Working Current: 16A/32A/40A/48A

Charging Display: LCD Screen

Output Plug: SAE J1772,Type1

Function: Plug&Charge/APP

Cable Length: 7.4M

Connectivity: OCPP 1.6 JSON (OCPP 2.0 compatible)

Network: Wifi (Optional for APP smart control)

Sample: Support

Customization: Support

OEM/ODM: Support

Certificate: ETL, FCC, Energy Star

IP Grade: IP65

Warranty: 2 years

Send email to us

Product Detail

Product Tags

Production Introduction

The iEVLEAD EV Charger provides a cost-effective solution for conveniently charging your EV at home, while meeting the charging standards for electric vehicles in North America (such as SAE J1772, Type 1). Featuring a user-friendly visual screen, seamless WIFI connectivity, and the ability to charge through a dedicated app, this charger offers a modern and convenient charging experience. Whether you choose to install it in your garage or near your driveway, the 7.4-meter cables provided are designed to reach your electric vehicle with ease. With the option to start charging immediately or set a delayed start time, you have the flexibility to save both money and time according to your preferences.

Features

1. Design that can support 11.5KW of power.
2. Compact and streamlined design for a minimalistic appearance.
3. Intelligent LCD screen for enhanced functionality.
4. Designed for home use with intelligent control through a mobile application.
5. Connected to the WIFI network for seamless communication.
6. Incorporate smart charging and load balancing capabilities.
7. Provide a high level of IP65 protection, ensuring durability in complex environments.

Specifications

Model				AB2-US11.5-WS
Input/Output Voltage				AC110-240V/Single Phase
Input/Output Current				16A/32A/40A/48A
Max Output Power				11.5KW
Frequency				50/60Hz
Charging Plug				Type 1 (SAE J1772)
Output Cable				7.4M
Withstand Voltage				2000V
Work Altitude				<2000M
Protection				over voltage protection, over load protection, over-temp protection, under voltage protection, earth leakage protection, lightning protection, short circuit protection
IP level				IP65
LCD Screen				Yes
Function				APP
Network				WIFI
Certification				ETL, FCC, Energy Star

Application

FAQs

1. What are your terms of delivery?
A: FOB, CFR, CIF, DDU.

2. Are you a factory or trading company?
A: We are a professional manufacturer of new and sustainable energy applications .

3. How do you guarantee the quality?
A: We have 100% test before delivery, the warranty time is 2 years.

4. What is a wall mounted EV charger?
A: A wall mounted EV charger is a device installed on a wall or other stationary structure that allows electric vehicles to charge their batteries. It provides a convenient and efficient way of charging an EV at home or in a business setting.

5. How does a wall mounted EV charger work?
A: The charger is connected to a power source, such as a household electrical circuit or a dedicated charging station, and is designed to provide the correct voltage and current for charging an EV. When the vehicle is plugged into the charger, it communicates with the car's battery management system to control the charging process.

6. Can I install a wall mounted EV charger at home?
A: Yes, many wall mounted EV chargers are specifically designed for residential use. However, it is important to consult an electrician to ensure that your home's electrical system can handle the additional load and to make sure the installation is done correctly.

7. How long does it take to charge an electric vehicle with a wall mounted EV charger?
A: The charging time depends on several factors, including the vehicle's battery size, the charger's power output, and the state of charge of the battery when charging begins. Generally, it can take anywhere from a few hours to overnight to fully charge an electric vehicle.

8. Can I use a wall mounted EV charger for multiple electric vehicles?
A: Some wall mounted EV chargers support multiple vehicle charging. These chargers may have multiple charging ports or be installed in a manner that allows for multiple vehicles to be charged using the same device. However, it is important to check the charger's specifications to ensure compatibility.
