iEVLEAD EU Waterproof Evse Rfid Card 1phase


  • Model: AA1-EU7
  • Max. Output Power: 7KW
  • Working Voltage: 230V AC Single phase
  • Working Current: 32A
  • Charging Display: LED light indicator
  • Output Plug: IEC 62196, Type 2
  • Input Plug: NONE
  • Output Plug: Type2
  • Function: Plug&Charge / RFID
  • Installation: Wall-mount/Pile-mount
  • Cable Length: 5m
  • Sample: Support
  • Customization: Support
  • OEM/ODM: Support
  • Certificate: CE
  • IP Grade: IP65
  • Warranty: 2 years
  • Product Detail

    Product Tags

    Production Introduction

    iEVLEAD prides itself on bringing to market innovative, quality products that further our mission of slowing climate change by reducing greenhouse gas emissions caused by transportation. Our principal line of products and services include EV charging equipment and our proprietary Joint Network.

    Features

    IP65 Waterproof for All Weather Use.
    5M Long Cable for Convenient Charging.
    The swipe function makes it safer for you to use.
    Designed with 12 advanced safety features.

    Specifications

    iEVLEAD 32A EV Charger 22KW 5m Cable
    Model No.: AA1-EU7 Bluetooth Optinal Certification CE
    Power Supply 7kW WI-FI Optional Warranty 2 years
    Rated Input Voltage 230V AC 3G/4G Optional Installation Wall-mount/Pile-mount
    Rated Input Current 32A Ethernet Optional Work Temperature -30℃~+50℃
    Frequency 50/60Hz OCPP OCPP1.6Json/OCPP 2.0 (optional) Work Humidity 5%~+95%
    Rated Output Voltage 230V AC Energy Meter MID Certified(optional) Work Altitude <2000m
    Rated Power 7KW RCD 6mA DC Product Dimension 330.8*200.8*116.1mm
    Standby Power <4W Ingress Protection IP65 Package Dimension 520*395*130mm
    Charge Connector Type 2 Impact Protection IK08 Net Weight 5.5kg
    LED Indicator RGB Electrical Protection Over current protection Gross Weight 6.6kg
    Cable Legth 5m Residual current protection External Package Carton
    RFID Reader Mifare ISO/IEC 14443A Ground protection
    Enclosure PC Surge protection
    Start Mode Plug&Play/RFID card/APP Over/Under Voltage protection
    Emergency Stop NO Over/Under temperature protection

    Application

    ap01
    ap02
    ap03

    FAQs

    Q1: How long is your delivery time?
    A: For small order,it usually takes 7 working days. For OEM order, please check the shipping time with us.

    Q2: How can we guarantee quality?
    A: Always a pre-production sample before mass production; Always final Inspection before shipment.

    Q3: What are your terms of delivery?
    A: FOB, CFR, CIF, DDU.

    Q4: An EV charger, or electric vehicle charger, is a device used to supply power to charge an electric vehicle. It provides electricity to the vehicle's battery, allowing it to run efficiently.

    Q5: How does an EV charger work?
    Electric vehicle chargers are connected to a power source, such as the grid or renewable energy sources. When an EV is plugged into a charger, power is transferred to the vehicle's battery through the charging cable. The charger manages the current to ensure safe and efficient charging.

    Q6: Can I install an EV charger at home?
    Yes, it is possible to install an EV charger in your home. However, the installation process may vary, depending on the type of charger and your home's electrical system. It is recommended to consult a professional electrician or contact the charger manufacturer for guidance on the installation process.

    Q7: Are EV chargers safe to use?
    Yes, EV chargers are designed with safety in mind. They go through a rigorous testing and certification process to ensure compliance with electrical safety standards. It is important to use a certified charger and follow proper charging procedures to reduce any potential risks.

    Q8: Are EV chargers compatible with all EVs?
    Most EV chargers are compatible with all EVs. However, it is important to ensure that the charger you use is compatible with your particular vehicle make and model. Different vehicles may have different charging port types and battery requirements, so it's crucial to check before connecting a charger.
