iEVLEAD EU Wall-Mounted Commercial EV Charging Stations


  • Model: AA1-EU11
  • Max. Output Power: 11KW
  • Working Voltage: 400 V AC Three phase
  • Working Current: 16A
  • Charging Display: LED light indicator
  • Output Plug: IEC 62196, Type 2
  • Input Plug: NONE
  • Function: Plug&Charge / RFID
  • Installation: Wall-mount/Pile-mount
  • Cable Length: 5m
  • Sample: Support
  • Customization: Support
  • OEM/ODM: Support
  • Certificate: CE
  • IP Grade: IP65
  • Warranty: 2 years
  • Product Detail

    Product Tags

    Production Introduction

    The EV charger offered provides power to all electric vehicles. Its wall-mounted and Pile-mounted designs, along with IP65 dust and waterproof housing, make it suitable for indoor and outdoor use.

    Features

    IP65 Waterproof & Dustproof.
    5M Long Cable for Convenient Charging.
    Swipe card function, more security and convenience Use.
    Don't waste time with high speed Charging.

    Specifications

    iEVLEAD 32A EV Charger 11KW 5m Cable
    Model No.: AA1-EU11 Bluetooth Optinal Certification CE
    Power Supply 11kW WI-FI Optional Warranty 2 years
    Rated Input Voltage 400V AC 3G/4G Optional Installation Wall-mount/Pile-mount
    Rated Input Current 32A Ethernet Optional Work Temperature -30℃~+50℃
    Frequency 50Hz OCPP OCPP1.6Json/OCPP 2.0 (optional) Work Humidity 5%~+95%
    Rated Output Voltage 400V AC Energy Meter MID Certified(optional) Work Altitude <2000m
    Rated Power 11KW RCD 6mA DC Product Dimension 330.8*200.8*116.1mm
    Standby Power <4W d IP65 Package Dimension 520*395*130mm
    Charge Connector Type 2 Impact Protection IK08 Net Weight 5.5kg
    LED Indicator RGB Electrical Protection Over current protection Gross Weight 6.6kg
    Cable Legth 5m Residual current protection External Package Carton
    RFID Reader Mifare ISO/IEC 14443A Ground protection
    Enclosure PC Surge protection
    Start Mode Plug&Play/RFID card/APP Over/Under Voltage protection
    Emergency Stop NO Over/Under temperature protection

    Application

    ap01
    ap02
    ap03

    FAQs

    Q1: Can you produce according to the samples?
    A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

    Q2: Do you offer OEM services?
    A: Yes, we offer OEM services for our EV chargers.

    Q3: What's the product warranty policy?
    A: All the goods purchased from our company can enjoy three year free warranty.

    Q4: What is an EV charger?
    An EV charger, or electric vehicle charger, is a device used to supply power to charge an electric vehicle. It provides electricity to the vehicle's battery, allowing it to run efficiently.

    Q5: How does an EV charger work?
    Electric vehicle chargers are connected to a power source, such as the grid or renewable energy sources. When an EV is plugged into a charger, power is transferred to the vehicle's battery through the charging cable. The charger manages the current to ensure safe and efficient charging.

    Q6: Can I install an EV charger at home?
    Yes, it is possible to install an EV charger in your home. However, the installation process may vary, depending on the type of charger and your home's electrical system. It is recommended to consult a professional electrician or contact the charger manufacturer for guidance on the installation process.

    Q7: Are EV chargers safe to use?
    Yes, EV chargers are designed with safety in mind. They go through a rigorous testing and certification process to ensure compliance with electrical safety standards. It is important to use a certified charger and follow proper charging procedures to reduce any potential risks.

    Q8: Are EV chargers compatible with all EVs?
    Most EV chargers are compatible with all EVs. However, it is important to ensure that the charger you use is compatible with your particular vehicle make and model. Different vehicles may have different charging port types and battery requirements, so it's crucial to check before connecting a charger.
