iEVLEAD 7kw EV Household Charging Cable Charge


  • Model: AD1-EU7
  • Max. Output Power: 7.4KW
  • Working Voltage: 230 V AC Single phase
  • Working Current: 32A
  • Display Screen: 3.8-inch LCD screen
  • Charge Mode: IEC 62196-2, Type 2
  • Input Plug: NONE
  • Function: Smart phone APP Control, Tap card control, Plug-and-charge
  • Installation: Wall-mount/Pile-mount
  • Cable Length: 5m
  • Sample: Support
  • Customization: Support
  • OEM/ODM: Support
  • Certificate: CE
  • IP Grade: IP55
  • Warranty: 2 years
  • Product Detail

    Product Tags

    Production Introduction

    iEVLEAD supply smart outdoor electric vehicle charge station socket for car charging.come up with IEC 62196-2 compliant,output of 7kW-22kW power, 3.8'' LCD screen, able to connect to WI-FI and 4G.

    Features

    Exquisitely sleek and compact design.
    Ensure your cost savings and provide peace of mind.
    The flexibility to work with any home.
    The charger's compatibility with various electric vehicle models.

    Specifications

    iEVLEAD 7kw EV Household Charging Cable Charge
    Model No.: AD1-EU7 Bluetooth Optional Certification CE
    AC Power Supply 1P+N+PE WI-FI Optional Warranty 2 years
    Power Supply 7.4kW 3G/4G Optional Installation Wall-mount/Pile-mount
    Rated Input Voltage 230V AC LAN Optional Work Temperature -30℃~+50℃
    Rated Input Current 32A OCPP OCPP1.6J Storage Temperature -40℃~+75℃
    Frequency 50/60Hz Impact Protection IK08 Work Altitude <2000m
    Rated Output Voltage 230V AC RCD Type A+DC6mA (TUV RCD+RCCB) Product Dimension 455*260*150mm
    Rated Power 7.4KW Ingress Protection IP55 Gross Weight 2.4kg
    Standby Power <4W Vibration 0.5G, No acute vibration and impation
    Charge Connector Type 2 Electrical Protection Over current protection ,
    Display Screen 3.8 inch LCD Screen Residual current protection,
    Cable Legth 5m Ground protection,
    Relative humidity 95%RH, No water droplet condensation Surge protection,
    Start Mode Plug&Play/RFID card/APP Over/Under Voltage protection,
    Emergency Stop NO Over/Under temperature protection

    Application

    ap01
    ap02
    ap03

    FAQs

    Q1: What is the warranty?
    A: 2 years. In this period, we will supply technical support and replace the new parts by free, customers are in charge of delivery.

    Q2: Are you a factory or a trading company?
    We are a professional manufacturer of new and sustainable energy applications in China and overseas sales team. Have 10 years of export experience.

    Q3: What is your sample policy?
    We can supply the sample if We have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

    Q4: How does a smart residential EV charger work?
    A smart residential EV charger is installed at home and connects to the electrical grid. It uses a standard power outlet or a dedicated circuit to supply electricity to the electric vehicle and charges the vehicle's battery using the same principles as any other charging station.

    Q5: Do smart residential EV chargers have built-in safety features?
    A: Yes, smart residential EV chargers typically come with built-in safety features to protect against overcharging, overheating, and electrical faults. These features include automatic current adjustment, ground fault protection, temperature monitoring, and short-circuit prevention.

    Q6: Can I use a smart residential EV charger outdoors?
    A: Yes, there are smart residential EV chargers specifically designed for outdoor use. These chargers are weatherproof and built to withstand various outdoor conditions, providing a reliable charging solution for electric vehicle owners who prefer to install the charger in their garage or outside their home.

    Q7: Does using a smart residential EV charger increase my electricity bill significantly?
    A: Using a smart residential EV charger may increase your electricity bill, but the impact depends on factors such as your electric vehicle's charging requirements, charging frequency, electricity rates, and any off-peak charging options you may utilize. However, many electric vehicle owners still find that charging at home is more cost-effective compared to relying solely on public charging stations.

    Q8: Are smart residential EV chargers backwards compatible with older electric vehicle models?
    A: Smart residential EV chargers are typically compatible with both older and newer electric vehicle models, regardless of the release year. As long as your electric vehicle uses a standard charging connector, it can be charged using a smart residential EV charger, regardless of its age.
