iEVLEAD 9.6KW EV Home Car Wall Charger


  • Model: AA1-US10
  • Max. Output Power: 9.6KW
  • Working Voltage: 240 V AC
  • Working Current: 40A
  • Charging Display: LED light indicator
  • Output Plug: NEMA 6-50/ NEMA 14-50
  • Function: Plug&Charge / RFID Card
  • Card Reader: RFID
  • Installation: Wall-mount/Pile-mount
  • Cable Length: 24.6 ft.
  • Sample: Support
  • Customization: Support
  • OEM/ODM: Support
  • Certificate: ETL
  • IP Grade: IP65
  • Warranty: 2 years
  • Product Detail

    Product Tags

    Production Introduction

    We support our consumers with ideal top quality products and higher level services. Becoming the specialist manufacturer in this sector, we have now obtained prosperous practical working experience in producing and managing for OEM Supply China 16A SAEJ1772 Electric Car Chargeing Unit with Type 1 Cable, We maintain timely delivery schedules, innovative designs, top quality and transparency for our buyers. Our purpose should be to supply quality goods inside of stipulated time.

    Features

    IP65 Rated, Durable, water and dust-tight.
    24.6 ft. Cable, Flexible for hard-to-reach locations.
    Our electric car charger is equipped with a NEMA 14-50 plug, making installation a breeze.
    Swipe the RFID tag for secure and efficient charging.
    Colorful choices to match your preference.

    Specifications

    iEVLEAD 10W EV Home Car Wall Charger
    Model No.: AA1-US10 Bluetooth Optinal Certification ETL
    Power Supply 10kW WI-FI Optional Warranty 2 years
    Rated Input Voltage 240V AC 3G/4G Optional Installation Wall-mount/Pile-mount
    Rated Input Current 40A Ethernet Optional Work Temperature -30℃~+50℃
    Frequency 60Hz Ground Fault Deteaction CCID 20 Work Humidity 5%~+95%
    Rated Output Voltage 240V AC Status Display LED Work Altitude <2000m
    Rated Power 10KW RCD Product Dimension 330.8*200.8*116.1mm
    AC Power Input Rating Max 9.6kw Ingress Protection IP65 Package Dimension 520*395*130mm
    Charge Connector Type 1 Inpact Protection IK08 Net Weight 5.5kg
    LED Indicator RGB Electrical Protection Over current protection Gross Weight 6.6kg
    Cable Legth 24.6 ft. (7.5m) Residual current protection External Package Carton
    Card Reader RFID Ground protection
    Enclosure PC Surge protection
    Charging Mode Plug-and-charge/RFID card Over/Under Voltage protection
    Emergency Stop NO Over/Under temperature protection

    Application

    ap01
    ap02
    ap03

    FAQs

    Q1: Can I get a lower price if I order large quantities?
    A: Yes, the larger the quantity, the lower the price.

    Q2: How can we guarantee quality?
    Always a pre-production sample before mass production; Always final Inspection before shipment;

    Q3: Are you a factory or trading company?
    A: We are a professional manufacturer of new and sustainable energy applications.

    Q4: What is an EV charger?
    An EV charger, or electric vehicle charger, is a device used to supply power to charge an electric vehicle. It provides electricity to the vehicle's battery, allowing it to run efficiently.

    Q5: How does an EV charger work?
    Electric vehicle chargers are connected to a power source, such as the grid or renewable energy sources. When an EV is plugged into a charger, power is transferred to the vehicle's battery through the charging cable. The charger manages the current to ensure safe and efficient charging.

    Q6: Can I install an EV charger at home?
    Yes, it is possible to install an EV charger in your home. However, the installation process may vary, depending on the type of charger and your home's electrical system. It is recommended to consult a professional electrician or contact the charger manufacturer for guidance on the installation process.

    Q7: Are EV chargers safe to use?
    Yes, EV chargers are designed with safety in mind. They go through a rigorous testing and certification process to ensure compliance with electrical safety standards. It is important to use a certified charger and follow proper charging procedures to reduce any potential risks.

    Q8: Are EV chargers compatible with all EVs?
    Most EV chargers are compatible with all EVs. However, it is important to ensure that the charger you use is compatible with your particular vehicle make and model. Different vehicles may have different charging port types and battery requirements, so it's crucial to check before connecting a charger.
